Hardness testerRockwell CiHo+ SRDLab Series
MODEL Rockwell CiHo+ SRD
HOYTOM® LAB Series
This model has been developed to perform tests using the Rockwell scale (with loads of 60, 100 and 150 kp), and the Rockwell superficial scale ( loads of 15, 30 and 45 kp), but can also apply additional loads for other tests, such as Brinell or Vickers It is comprised of a motorised frame, where the load application systems are installed (which employ a computer controlled force transducer).
Indentation depth is measured by a sensor with a resolution of 0.1 microns (0.0001 mm).
The Rockwell system is used to test parts made of metal, plastic, rubber, etc.
The Rockwell indenter can move horizontally and vertically to test different points on large parts.
- Touch screen with microprocessor (Hoytom)
- Direct read-out on 15” touch screen
- Read-out system
- Statistical calculations (average, deviation, travel, etc.)
- Results in database (.mdb)
3 year warranty
When you purchase a Hoytom machine it comes with a 3 year warranty. Hoytom machines are manufactured according to the most stringent standards.
HBM load cells
Hoytom has placed its trust in HBM, a leading technology and product and services company that produces a wide range of measurement applications for numerous industries.
Optional accessories
Technical characteristics
| Preloads Kgf | 3 and 10 |
| Rockwell superficial scale loadsKgf | 15, 30 and 45 |
| Rockwell loadsKgf | 60, 100 and 150 |
| Brinell loads Kgf | 31.25, 62.5, 125, 187.5, 250 |
| Vickers loads Kgf | 3, 5, 10, 20, 30, 60 and 100 |
| Load application speed | automatically adjusted |
| Test load selection | via touch screen |
| Load cell | HBM® (international leader in this technology) |
| Vertical capacity mm | 650 |
| Space between columns mm | 900 |
| Dimensions (WxDxH) mm | 1140 x 1160 x 1720 |
Standards
EN ISO 6508, ASTM E18
See more
EN ISO 6506, ASTM E10, EN ISO 6508, ASTM E18
